Production Description
 |
|
|
| Optical System | Finity Optical System |
| Eyepiece | Wide Field Plan-scope Eyepiece: WF10X/18mm; One Diopter Adjustment ±5 |
| Objective | 45mm DIN Achromatic Objective：4X,10X,40X(S),100X(S,Oil) |
| Viewing Head | Articulated Free Trinocular Head, 30°inclined, Interpupillary Distance 52-75mm |
| Nosepiece | Backward Quadruple Objective Nosepiece |
| Stage | 188X120mm Double Mechanical Stage，50X70mm,Presion 0.1mm |
| Condenser | N.A. 1.25 Abbe Condenser with Diaphragm |
| Focusing System | Coaxial Coarse and Fine Focus Knobs, Precision 0.002mm,Focusing Range: 16mm |
| Illumination | 1W LED Lamp Illumination System |
| Optional | 1.Dry Darkfield Condenser, Oil-darkfiled Condenser 2.Plan Objective Set、Infinity Plan Achromatic Objective Set 3. Articulated Free Binocular Head |
| Net Weight | 5KG |
Package
2sets/foam+carton
Carton Dimension：51X40X52cm
G.W: 13kg
